FLIPSCREEN® Screening Buckets
Flipscreen BL65-4 (5-9 Ton carriers)
Width: 91″
Height: 59″
Scoop Size: .85 Yard
Capacity: 2.9 Yard
Bucket Opening: 81″ x 17″
Required Flow: 15.4 GPM
Pressure: 2248 psi
Screen Area: 44 sq ft.
(Estimate screening rate of topsoil & Rock with 2″/50mm screen: 94 yards/hour)
RESERVE FOR MARCH 2027!
Price: $Contact for Pricing
CLICK IMAGE FOR MORE INFO
Flipscreen BL95-4 (8-12 Ton carriers)
Width: 96″
Height: 54″
Scoop Size: 1.13 Yard
Capacity: 3.0 Yard
Bucket Opening: 81″ x 20″
Required Flow: 18 GPM
Pressure: 2900 psi
Screen Area: 44 sq ft.
(Estimate screening rate of topsoil & Rock with 2″/50mm screen: 120 yards/hour)
RESERVE FOR MARCH 2027!
Price: $Contact for Pricing
CLICK IMAGE FOR MORE INFO
Flipscreen BL130-4 (11-16 Ton carriers)
Width: 97″
Height: 63″
Scoop Size: 1.7 Yard
Capacity: 5.1 Yard
Bucket Opening: 84″ x 26″
Required Flow: 32 GPM
Pressure: 2467 psi
Screen Area: 44 sq ft.
Weight: 4057 lbs
(Estimate screening rate of topsoil & Rock with 2″/50mm screen: 200 yards/hour)
RESERVE FOR MARCH 2027!
Price: $Contact for Pricing
CLICK IMAGE FOR MORE INFO
Flipscreen BL180-4 (11-18 Ton carriers)
Width: 114″
Height: 67″
Scoop Size: 2.36 Yard
Capacity: 7.0 Yard
Bucket Opening: 96″ x 24″
Required Flow: 32 GPM
Pressure: 2467 psi
Screen Area: 73 sq ft.
Weight: 3792 lbs
(Estimate screening rate of topsoil & Rock with 2″/50mm screen: 276 yards/hour)
RESERVE FOR MARCH 2027!
Price: $Contact for Pricing
CLICK IMAGE FOR MORE INFO
Flipscreen BL185-4 (11-23 Ton carriers)
Width: 109″
Height: 67″
Scoop Size: 2.36 Yard
Capacity: 7.0 Yard
Bucket Opening: 96″ x 24″
Required Flow: 39 GPM
Pressure: 2538 psi
Screen Area: 74 sq ft.
Weight: 3800lbs
(Estimate screening rate of topsoil & Rock with 2″/50mm screen: 276 yards/hour)
RESERVE FOR MARCH 2027!
Price: $Contact for Pricing
CLICK IMAGE FOR MORE INFO
Flipscreen BL280-4 (11-23 Ton carriers)
“Engineered for high volume, extreme environments, mining & quarrying”
Width: 143″
Height: 90″
Scoop Size: 3.66 Yard
Capacity: 11.0 Yard
Bucket Opening: 116″ x 30″
Required Flow: 48 GPM
Pressure: 3771 psi
Screen Area: 110 sq ft.
Weight: 9700 lbs
(Estimate screening rate of topsoil & Rock with 2″/50mm screen: 384 yards/hour)
RESERVE FOR MARCH 2027!
Price: $Contact for Pricing
CLICK IMAGE FOR MORE INFO
Flipscreen BL285 WMD-4 (12-21 Ton carriers)
WL285 Wastermater – tranforms your loader into a fully-mobile, high-volume screening plant”
Width: 143″
Height: 90″
Scoop Size: 3.75 Yard
Capacity: 11.17 Yard
Bucket Opening: 116″ x 30″
Required Flow: 48 GPM
Pressure: 3771 psi
Screen Area: 110 sq ft.
Weight: 9700 lbs
(Estimate screening rate of topsoil & Rock with 2″/50mm screen: 384 yards/hour)
RESERVE FOR MARCH 2027!
Price: $Contact for Pricing
CLICK IMAGE FOR MORE INFO
